Medium silica fiberglass fabric (SiO₂ content: 70%±5%) is a high-temperature resistant inorganic fiber material designed as a cost-effective alternative to high-silica fiberglass in moderate-temperature applications. It is asbestos-free and non-hazardous, offering balanced thermal and mechanical performance for industrial use.

Return to List

Product Features

Temperature Resistance: Continuous use at 800°C | Short-term exposure to 1000°C
Material Safety: Contains no asbestos or ceramic cotton; fully health-compliant
Enhanced Performance: Lower thermal conductivity than high-silica fiberglass with superior tensile strength (30% higher than standard fiberglass)
Electrical Properties: Volume resistivity >10¹² Ω·cm at 800°C
Physical Durability: 50% better wear resistance than conventional fiberglass fabrics

Sizes

Model and Specification

Model	Temp. (°C)	Weight (g/m²)	Thickness (mm)	Width (mm)	Length (m)	SiO₂ (%)
HMMS400	800	400±30	0.4±0.10	920-1500	100	70±5
HMMS600	800	650±30	0.75±0.05	920-1500	46	70±5
HMMS1100	800	1150±30	1.30±0.10	920-1500	46	70±5
HMMS1200	800	1250±30	1.35±0.10	920-1500	46	70±5

Application

1. Welding & Thermal Protection

Insulation blankets, heat preservation covers, and sealing gaskets for welding operations up to 1000°C.

2. Aerospace Thermal Management

Ablation materials for rocket nozzles and re-entry vehicle thermal protection systems.

3. Fireproofing Solutions

Fire-resistant clothing, industrial curtains, and firefighting equipment with EN13501-1 certification.

4. High-Temperature Filtration

Molten metal filtration media and exhaust gas purification systems for foundries.

5. Energy Sector Insulation

Nuclear power plant cable wraps, turbine exhaust insulation, and steam pipeline expansion joints.

Remarks

Custom widths (up to 3.5m) and lengths available
Optional silicone/PTFE coatings for enhanced chemical resistance
MOQ: 100m for standard models; 50m for custom specifications
Lead time: 7-15 days for stock items; 4-6 weeks for customized orders

Standard Complied

ASTM C1666 - Standard Specification for High Silica Fiberglass Fabrics
EN 13501-1 - Fire classification (Class A1 non-combustible)
ISO 1893 - Refractory products thermal shock testing
RoHS/REACH - Compliant with hazardous substance restrictions

This is a product showcase page. For pricing and purchasing, please contact our sales team.
